100GHz Add/Drop Module

Features Epoxy Free Low Insertion Loss High Reliability and Stability Polarization Independent	Applications DWDM Transmission System Optical Fiber Device Optical Fiber Amplifier System Wideband Networks
Specifications

Item	Unit	Parameter
Number of Add/Drop Channels		1 (2x2)	2 (3x3)	4 (5x5)
Add/Drop Center Wavelength (lc)	nm	ITU Channel±0.06
-0.5dB Bandwidth	nm	0.38
-25dB Bandwidth	nm	1.25
Typ. Add/Drop Insertion Loss@lad	dB	0.8	1.2	2.1
Max. Add/Drop Insertion Loss@lad	dB	1.0	1.5	2.4
Typ. Remain Insertion Loss@lp	dB	0.8	1.9	3.4
Max. Remain Insertion Loss@lp	dB	1.1	2.3	3.8
Min. Adjacent Isolation	dB	25
Min. No-Adjacent Isolation	dB	40
Min. Directivity	dB	50
Max. Polarization Dependent Loss	dB	0.1
Min. Return Loss	dB	45
Max. Thermal Stability	dB/°C	0.004	0.006	0.007
Max. Thermal Wavelength Drift	nm/°C	0.001
Max. Optical Power	mW	250
Operating Temperature	°C	0 ~ +65
Storage Temperature	°C	-40 ~ +85
Package Dimensions	dB	O:100x80x9 L:120x80x18 P:136x100x12 S:140x114x18 G:140x114x13

Ordering Information
